Pressmaster D-sub open barrel 0.08-0.5 mm2 high density types (4300-1224)

Pressmaster D-sub open barrel 0.08-0.5 mm2 high density types (4300-1224)

SKU PREDRB0805HD
by Pressmaster
Sold out
$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00
DRB 0805 HD DRB-0805 HD is a crimping tool for D-Sub connectors, High-Density, 0.08 - 0.50 mm²/ 28-20 AWG, B-Crimp, with locator. *High strength, through hardened alloy steel construction *Versatile and easy to customize for right hand or left hand users *Full cycle crimp mechanism to ensure consistent, reliable crimp *Ratchet release mechanism to clear miscrimps and obstructions *Precision eccentric adjustment for consistent performance and ability to calibrate *Each tool has a unique serial number for traceability
Features & Benefits

*High strength, through hardened alloy steel construction*Versatile and easy to customize for right hand or left hand users*Full cycle crimp mechanism to ensure consistent, reliable crimp*Ratchet release mechanism to clear miscrimps and obstructions*Precision eccentric adjustment for consistent performance and ability to calibrate*Each tool has a unique serial number for traceability

Specifications

*Length: 198 mm/7.8"Width: 18 mm/0.71"Height: 59 mm/2.32"Weight: 451 gr/0.99 lbWire size: 0.08-0.5 mm2 / AWG 28-AWG 20Crimp dimensions mm/mm2:0.08 - 0.22 mm2 (1/2D)/0.08 - 0.22 mm2/0.22 - 0.50 mm2Crimp dimensions inch/AWG:AWG 28 - AWG 24/AWG 28 - AWG 24/AWG 24 - AWG 20Connector: D-Sub High Density connectorDescription: Open barrel/Uninsulated D-Sub pins , high density only, standard typeLife span, cycles: 50,000
