Pressmaster Non-insulated open barrel 0.1-1.5 mm2 (4300-0199)

Pressmaster Non-insulated open barrel 0.1-1.5 mm2 (4300-0199)

SKU PREDRB0115
by Pressmaster
Sold out
$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00
The Pressmaster Non-insulated Open Barrel DRB0115 is a heavy-duty crimping tool designed to crimp non-insulated open barrel connectors. It accepts wire sizes of 0.1 mm² to 1.5 mm² (AWG 26 to AWG 16) and has a B/F-Crimp design for 2.8 mm and 4.8 mm connectors. The crimping tool provides accurate, reliable, and consistent crimping performance across a range of electrical and industrial applications. Applications: *Electrical: Ideal for crimping non-insulated open barrel connectors in electrical wiring systems to provide secure and reliable connections. *Automotive: Suitable for automotive electrical systems where the use of non-insulated open barrel connectors is prevalent. *Industrial: Ideal for industrial applications involving non-insulated connectors in heavy-duty wiring systems. *DIY and Maintenance: Ideal for professionals and DIYers who must crimp non-insulated open barrel connectors in repairs or installations.
Features & Benefits

*High Strength Construction: Made from through-hardened alloy steel, ensuring superior durability and long-lasting performance.*Versatile and Ergonomic Design: Adjustable for right and left-handed operators, promoting user comfort and efficiency.*Full Cycle Crimp Mechanism: Provides a consistent and reliable crimp with each use, ensuring high-quality performance.*Ratchet Release Mechanism: Includes a ratchet release to remove miscrimps and blockages, avoiding tool damage.*Precision Eccentric Adjustment: Provides the option to calibrate the tool, providing consistent crimp performance over time.*Traceability: Each tool has a unique serial number, providing traceability for quality control.*Long Life Span: Up to 50,000 crimping cycles rated, providing outstanding value for heavy-duty use.

Specifications

*Manufacturer: Pressmaster*Part Number: DRB0115 (4300-0199)*Tool Type: Crimping Tool for Non-insulated Open Barrel Connectors*Wire Size: 0.1-1.5 mm² (AWG 26-AWG 16)*Crimp Dimensions mm/mm²: 0.1 - 0.5 mm² / 0.5 - 1 mm² / 0.5 - 1.5 mm²*Crimp Dimensions inch/AWG: AWG 26 - AWG 20 / AWG 20 - AWG 18 / AWG 20 - AWG 16*Connector Type: Non-insulated Open Barrel Connectors (2.8 mm and 4.8 mm)*Length: 198 mm (7.8")*Width: 18 mm (0.71")*Height: 59 mm (2.32")*Weight: 350 gr (0.77 lb)*Life Span (Cycles): 50,000

More Information

Applications:*Electrical: Ideal for crimping non-insulated open barrel connectors in electrical wiring systems to provide secure and reliable connections.*Automotive: Suitable for automotive electrical systems where the use of non-insulated open barrel connectors is prevalent.*Industrial: Ideal for industrial applications involving non-insulated connectors in heavy-duty wiring systems.*DIY and Maintenance: Ideal for professionals and DIYers who must crimp non-insulated open barrel connectors in repairs or installations.
