Solder Bar Sn63/Pb37, 1kg

Solder Bar Sn63/Pb37, 1kg

SKU CON00540
by Misc
$0.00 - $0.00
$0.00
$136.00
$136.00 - $136.00
$136.00
Solder Bar Sn63/Pb37 is an alloy that is composed of 63% tin and 37% lead and results in a low drossing, high wetting solder. Package Size: 1kg

Stock available: 1

Features & Benefits

High purityReduces drossingSolder Bar Sn63/Pb37 is a eutectic alloy with a melting point of 183°C (361°F).Typical applications are wave soldering and plating where Sn63/Pb37 is primarily used as a coating for corrosion protection, and as a base for soldering. This alloy is available in bar, solid and cored wire, foil, spheres, preforms, powder, solder paste, ingot, and anode form.Solder Bar Sn63/Pb37 is compatible with most electronic grade fluxes.

Specifications

Type: BarAlloy: Sn63/Pb37Melting temperature 183° C (361°F)Meets IPC-J-STD-006 SpecificationsPackage Size: 1kg
