Electrolube ER2183 Black Low Viscosity, Thermally Conductive Epoxy 5kg - ER2183K5K - ELER2183K5K

SKU ELER2183K5K
Order In
Original price $0.00 - Original price $0.00
Original price $0.00
$0.00
$0.00 - $0.00
Current price $0.00
Electrolube ER2183 Black Low Viscosity, Thermally Conductive Epoxy 5kg - ER2183K5K 5kg kit .. ER2183 Thermally conductive epoxy potting compound is an epoxy resin which meets UL94 flame retardancy using clean technology which results in relatively low toxicity fumes and low smoke emission. It is a low viscosity alternative to ER2220 system which is ideal for potting and encapsulating electronics or components with limited spacing and where thermal dissipation is required. It has a wide operating temperature range and can be used in a variety of potting and encapsulation applications.
Features & Benefits

Thermally Conductive Epoxy Low viscosity alternative to ER2220: 5000mPa s High thermal conductivity; 1.25W/m.K Easy to mix, uses non-abrasive fillers Wide operating temperature (-40°C to 130°C) Meets UL94 RoHS Compliant

Specifications

Manufacturer: ElectrolubePart Number: ELER2183K5K (ER2183)Product Type: Thermally Conductive Epoxy Potting CompoundColour: BlackKit Size: 5kgViscosity: Approximately 5000 mPa·sThermal Conductivity: 1.25 W/m.KOperating Temperature Range: -40°C to 130°CFlame Rating: Meets UL94Compliance: RoHS
