Hakko 470/474/701 Diaphram (2Pcs)

Hakko 470/474/701 Diaphram (2Pcs)

SKU HKA1013
by Hakko
Sold out
$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00
The Hakko A1013 is a set of two replacement diaphragm units designed for use with Hakko desoldering stations including the FR-410, FR-400, FM-204, 472D, 702, 703, 470, and 474 models. These diaphragms are essential to maintain vacuum performance in the built-in pump system that powers solder extraction.
Features & Benefits

*Replacement pump diaphragms engineered for Hakko desoldering stations with integrated vacuum systems.*Supplied as a 2-piece kit for consistent performance or dual maintenance.*Precision-made elastomer seals that restore reliable suction during solder removal.*Lightweight and compact design enables quick swap-out with minimal tool downtime.*Compatible with both FR-series and FM-series Hakko desoldering tools.

Specifications

*Manufacturer: Hakko*Part Number: A1013*SKU: HKA1013*Product Type: Pump diaphragm replacement set (2 pieces)*Compatible Stations: FR-410, FR-400, FM-204, 472, 472D, 702, 703, 474*Material: Flexible elastomer diaphragm for vacuum suction*Dimensions (each diaphragm): Approximately 56 mm × 53 mm × 2.5 mm*Weight per Diaphragm: Approximately 9 g each

More Information

Applications:*Restoring optimal suction performance in desoldering stations whose diaphragms have become worn or porous.*Ideal for routine maintenance of Hakko FR and FM series desoldering tools to ensure efficient heat and solder extraction.*Used in electronics repair workshops, prototyping laboratories, and manufacturing lines where desoldering tools require consistent vacuum operation.*Helps prevent incomplete solder removal, reducing downtime and improving user efficiency.*Ensures reliable vacuum seal integrity, especially in systems with high-frequency use or older components.

Operators Manual
