Aoyue H474 Desoldering Tool

Entry Level Economy Desolder tool

l Compact unit with air cylinder type strong suction vacuum pump.

l Suited for multi-layered PCB reworking.

l The heating element and tip are designed closely to guarantee enough temperature during desoldering.



Package content:

474 Station, B1002 Desoldering Gun, Desoldering tips (S, M, L), 3017J Filter pads, 6 pcs. H022 Silicone Grease, 201412 Desoldering gun holder, 201252 Filter pipe, 204242 Nozzle cleaning pin, Power cord.

Note: Newer tips has the tip and tube as one piece
Older units just the tip



SPECIFICATIONS:

Power Input :
220V

Power Consumption:
70W

Temperature Range:
150 - 380 degrees Celsius

Heating Element:
PTC Heating Element

Output Voltage:
24V

Tip to Ground Resistance:
Below 2 ohms

Tip to Ground Potential:
Below 2mV

Suction Flow:
15L/min (max)

Vacuum Generator:
Double Cylinder

Vacuum Pressure:
600mm Hg

Station Dimensions:
188(w) x 127(h) x 244(d) mm

Weight:
5.3Kg
