The Fisnar Mix Nozzle 6.4 mm ID × 24 Elements (Part No. 1670624) is a high-performance disposable static mixing nozzle designed for use with dual cartridges and meter-mix dispense machines. It features a bell-mouth inlet that easily fits over machine manifolds and contains 24 high-strength polyacetal mixing elements for effective and uniform blending of two-component materials. The body is made of natural polypropylene for pressure resistance and chemical compatibility. This nozzle is ideal for precise, mess-free mixing and dispensing of adhesives, sealants, and other reactive fluids.

Key Features:
*24 static mixing elements for optimal two-part blending.
*6.35 mm (0.250 inch) internal diameter accommodates medium- to high-viscosity materials.
*Bell-mouth entry for secure manifold connection.
*Stepped nozzle outlet for direct use or attachment of tips.
*Manufactured from industrial-grade polypropylene and polyacetal.
*Safe for use up to 100 psi.
*Silicone-free construction ensures compatibility with sensitive processes.

Specifications:
*Manufacturer: Fisnar
*Part number: 1670624
*Model: MS-Series Static Mixer
*Inner diameter: 6.35 mm (0.250 inch)
*Outer diameter: 10 mm (0.394 inch)
*Mixer length: 186 mm (7.32 inch)
*Number of elements: 24
*Material volume: 4.2 ml
*Body material: Polypropylene (natural)
*Mixing element material: Polyacetal (yellow)
*Max pressure: 33 bar (approx. 480 psi)
*Recommended operating pressure: Up to 100 psi
*Inlet type: Bell-mouth for meter mix manifold or cartridge
*Outlet type: Stepped nozzle (can be trimmed or adapted)

Applications
*Electronics: Mixing and dispensing of potting compounds, epoxy resins, and encapsulants.
*Automotive: Application of structural adhesives, sealants, and foam-in-place gasketing.
*Aerospace: Use with lightweight composite bonding agents and sealants.
*Construction: Injection of anchoring adhesives, crack repair compounds, and joint fillers.
*Manufacturing: General assembly, robotic dispensing lines, and precise multi-material mixing.
